Microscope for inspection of devices

For training, please contact the Tool Manager(s).

Training is available now for the Nikon Eclipse L200N microscope and Nikon Elements D software for image capture.

Compatibility:
5 - Class A and B Metals and Compounds
Additional Restrictions
  • Do not use wipes, which generate particles, on microscope stages. Place samples on microscope slides.
Manager
Alan R. Bleier
Backups:
Garry Bordonaro
Nikon Eclipse

The CNF has many optical microscopes. Digital cameras attached to the microscopes are available for taking images of your work.

The Nikon Eclipse L200N microscope and Nikon Elements D image capture software are the best optical microscopy system at CNF.

Features include:

  • Motorized objective change- permits quick observation changeovers (optional hand switch is available for direct selection of objectives)
  • A range of observation modes - including brightfield, darkfield, (Nomarski) DIC and polarized light
Equipment Information Sheet
Resources:
Nikon Eclipse L200N Microscope and Nikon Elements Image Capture Software Quick Start
